FAAC 740D Control Board Dubai UAE – IGTS

The FAAC 740D Control Board delivers professional 230V control for sliding gate operators throughout Dubai, Sharjah, Ajman, Abu Dhabi, and the wider UAE. This advanced control system features 1000W motor capacity, comprehensive programming with display, and multiple operating logics for maximum flexibility. Designed for FAAC 740/741 series operators, it provides sophisticated automation solutions with extensive safety features for residential and commercial properties across the Emirates.

KEY FEATURES

Power & Specifications

• Power Supply: 220-240V~ 50/60 Hz

• Max Power: 10W

• Motor Max Power: 1,000W

• Max Accessories Load: 0.5A

• Operating Temperature: -20°C to +55°C

Compatibility

• FAAC 740 sliding gate operators

• FAAC 741 operator systems

• 230V operator applications

• Professional gate automation

Programming & Control

• 3-key programming (+, -, F) with display

• Basic and advanced modes

• Multiple operating logics

• Comprehensive programmable functions

Operating Logics

• Automatic & Automatic Step by Step

• Semi-automatic & Semi-automatic Step by Step

• Safety mode

• Semi-automatic B & “Dead man” C/B/C mixed logic

TECHNICAL EXCELLENCE

Advanced Programming Capabilities

The FAAC 740D offers extensive programming options with 50-level thrust power adjustment, programmable work/pause times, and multiple operating logics. Additionally, the display interface provides clear status signaling and easy configuration for technicians across the UAE.

Comprehensive Safety Features

With anti-crushing sensitivity control, multiple safety inputs, and failsafe functionality, this control board ensures maximum protection during gate operation. Furthermore, the programmable safety device logics and edge detection provide layered security for all users.

Professional Integration

Featuring rapid connector support for MINIDEC, Decoder, and RP receivers, along with multiple terminal board inputs/outputs, this system offers seamless integration with various accessories. Moreover, the robust design ensures reliable performance in the UAE’s extreme temperature conditions.
