VDS PM 400

Description

VDS PM 400 Swing Gate Motor in Dubai UAE – Reversible 230V by IGTS Technical Services

The VDS PM 400 Swing Gate Motor is a durable and reversible electromechanical actuator designed for swing gates with leaves from 1.8 m up to 3.5 m. Its sturdy aluminum structure, stainless steel rod with dust scraper, and quiet operation make it ideal for residential and commercial gates.

With a 120° opening angle, thermal cut-out at 140°C, and manual release with a customized key, the VDS PM 400 ensures safe, reliable, and long-lasting performance. Quick installation is facilitated by multi-position brackets and a technopolymer cover for brackets, while lithium grease lubrication protects mechanical parts against corrosion and rust.

Available from IGTS Technical Services, this 230V swing gate motor meets EN 12453 safety standards with its anti-squashing system and slowing-down function.

Key Features of VDS PM 400 Swing Gate Motor

• Leaf Length: 1.8 m – 3.5 m

• Max Leaf Weight: 250 kg

• Rod Stroke Options: 300 mm, 400 mm, 600 mm

• Voltage: 230 VAC

• Reversible Electromechanical Motor

• Quiet Operation: < 30 dBA

• Thermal Cut-Out: 140°C

• Manual Release: Customized key

• Durable Aluminum Structure with Stainless Steel Rod

• Lithium Grease Lubrication for Corrosion Protection

• Opening Angle: 120°

• Quick Installation: Multi-position brackets & technopolymer cover

• Safety: Anti-squashing system & slowing down function (EN 12453)

VDS PM 400 Motor Kit Includes

• 1 x VDS PM 400 Swing Gate Motor

• 1 x Control Unit (if required, depending on installation)

• 1 x Manual Release Key

• 1 x Multi-position Brackets with Technopolymer Cover

• 1 x Set of Lithium Grease for Mechanical Parts
